Features:
1. Optimize the imaging effect within the working range of 600mm color selection standard.
2. M42*1 threaded interface, with the adapter interface can be matched with all kinds of interfaces.
型號
Model
F50DMB28
F50DMB40
F50DMB28
F50DMB40
焦距(mm)
Focal Length
50mm 50mm
50mm 50mm 標準放大倍率
Standad Magnificaition
0.0946 0.094 0.0946 0.094 像面尺寸(mm)
Image Size
φ30 φ30 φ30 φ30 光圈
Iris(F)
F2.8 F4 F2.8 F4
光學畸變
Optical Distortion
-0.61% -0.61% -0.61% -0.61% 相對照度(%)
Relative Illuminace
95.5% 95.5% 95.5% 95.5% 工作距離(mm)
Working Distance
574 574 574 574 最優工作距離(mm)
Optimal Working Distance
600mm-700mm 600mm-700mm 600mm-700mm 600mm-700mm 接口
Mount
M42*1 M42*1 M42*1 M42*1 法蘭距(mm)
Flange Length
12 12 5.9 5.9 分辨率
Resolution
5.5K 5μ 5.5K 5μ 5.5K 5μ 5.5K 5μ -
-
